Power supply MDR-20-5 for DIN rail

Name: Power supply MDR-20-5 for DIN rail
Brand: Mean Well
SKU: V96356
Price: 11.70 GBP
Availability: OutOfStock

Brand: Mean Well Product Code: V96356

All about product

Description

Specification

Reviews 0

Questions0

new

Popular

Sold Out

Out Of Stock

£11.70

Compatibility:Raspberry Pi 4 Model B, Raspberry Pi 3 Model B+, Raspberry Pi 3 Model B, Raspberry Pi 3 Model A+, Raspberry Pi 2 Model B v1.2, Raspberry Pi 1 Model B+, Raspberry Pi 1 Model A+, Raspberry Pi Zero/Zero W, Raspberry Pi Compute Module 3+ Development Kit, NVIDIA Jetson Nano Developer Kit

Country of origin:Made in China

Output current:3.0 A

Output voltage:5.0 V

Power:15.0 W

Delivery

Royal Mail 1st Class

£3.50

DHL Express

£9.99

Payment

ApplePay

Google Pay

bank transfer

Secure Payment

Your payment information is processed securely.
We do not store credit card details.

Power supply MDR-20-5 for DIN rail

£11.70

Description

MDR-20-5 DIN rail power supply TS35 is designed to reduce the mains voltage 110/230V (50-60Hz) to a stabilized level of 5V 3A.

Characteristics of MDR-20-5:

Output power: 15 W
Output voltage: 5 V
Output current: 3 А
Dimensions: 22.5 x 90 x 100 mm

Features of the power supply:

wide range of input voltage
built-in protection against: short circuit, overload, overvoltage
passive air cooling
mounted on a standard DIN rail TS35
built-in light indicator for network connection
DC OK indication signal
power consumption without payload - no more than 0.75W

Theunit is mounted on a standard DIN rail TS35.

Overall dimensions: 22.5mm x 90mm x 100mm

Specifications

Main characteristics

Compatibility

Raspberry Pi 4 Model B, Raspberry Pi 3 Model B+, Raspberry Pi 3 Model B, Raspberry Pi 3 Model A+, Raspberry Pi 2 Model B v1.2, Raspberry Pi 1 Model B+, Raspberry Pi 1 Model A+, Raspberry Pi Zero/Zero W, Raspberry Pi Compute Module 3+ Development Kit, NVIDIA Jetson Nano Developer Kit

Country of origin

Made in China

Output current

3.0 A

Output voltage

5.0 V

Power

15.0 W

Power connector

terminal block

Type of accessory

Power supply
