Arduino MKR FOX 1200 / ABX00014

Name: Arduino MKR FOX 1200 / ABX00014
Brand: Arduino
SKU: V70378
Price: 39.75 GBP
Availability: OutOfStock

Brand: Arduino Product Code: ABX00014

All about product

Description

Specification

Reviews 0

Questions0

new

Popular

Sold Out

Out Of Stock

£39.75

Country of origin:Made in Italy

Series:MKR Family

Type:Boards & Modules

Delivery

Royal Mail 1st Class

£3.50

DHL Express

£9.99

Payment

ApplePay

Google Pay

bank transfer

Secure Payment

Your payment information is processed securely.
We do not store credit card details.

Arduino MKR FOX 1200 / ABX00014

£39.75

Description

Arduino MKR FOX 1200 is a board based on the Atmel SAMD21 and ATA8520 SigFox module. The board was designed specifically to simplify the connection of SigFox. It is especially useful for those who have not yet encountered this type of connection.

The first and most important feature is that the board can be powered by two 1.5V AA and AAA batteries, in addition to the standard 5V external power supply. Switching from one source to another is automatic.

This model is equipped with good computing power, it also has a rich set of I/O interfaces and energy-efficient SigFox communication function.

In addition, ARDUINO offers its own Arduino Software development environment, which greatly simplifies the entire time-consuming programming process.

All of the above makes this platform the best for creating new battery-powered IoT projects.

Technical specifications:

Microcontroller.	SAMD21 Cortex-M0+ 32bit low power ARM MCU
Input voltage (recommended) (USB/VIN)	5V
Supported battery type	2x AA or AAA
Operating voltage	3.3V
Digital outputs (I/O Pins)	8
PWM pins	12 (0, 1, 2, 3, 4, 5, 6, 7, 8, 10, A3 - or 18 -, A4 -or 19)
UART	1
SPI	1
I2C	1
Analog outputs (input)	7 (ADC 8/10/12 bit)
Analog outputs (output)	1 (DAC 10 bit)
External interrupts	8 (0, 1, 4, 5, 6, 7, 8, A1 -or 16-, A2 -or 17)
Max. value of DC current per 1 pin (I/O Pin)	7 mA
Flash memory	256 KB
SRAM	32 KB
EEPROM	no
Frequency	32.768 kHz (RTC), 48 MHz
LED_BUILTIN	6
Full-speed USB device and built-in host
Antenna power	2dB
Carrier frequency	868 MHz
