Power supply MDR-40-5 for DIN rail

Name: Power supply MDR-40-5 for DIN rail
Brand: Mean Well
SKU: V96355
Price: 16.90 GBP
Availability: OutOfStock

Brand: Mean Well Product Code: V96355

All about product

Description

Specification

Reviews 0

Questions0

new

Popular

Sold Out

Out Of Stock

£16.90

Compatibility:Raspberry Pi 4 Model B, Raspberry Pi 3 Model B+, Raspberry Pi 3 Model B, Raspberry Pi 3 Model A+, Raspberry Pi 2 Model B v1.2, Raspberry Pi 1 Model B+, Raspberry Pi 1 Model A+, Raspberry Pi Zero/Zero W, Raspberry Pi Compute Module 3+ Development Kit, NVIDIA Jetson Nano Developer Kit

Country of origin:Made in China

Output current:6.0 A

Output voltage:5.0 V

Power:30.0 W

Delivery

Royal Mail 1st Class

£3.50

DHL Express

£9.99

Payment

ApplePay

Google Pay

bank transfer

Secure Payment

Your payment information is processed securely.
We do not store credit card details.

Power supply MDR-40-5 for DIN rail

£16.90

Description

TheMDR-40-5 DIN rail power supply is designed to reduce the mains voltage of 110/230V (50-60Hz) to a stabilized level of 5V 6A.

Characteristics of MDR-40-5:

Output power: 30 W
Output voltage: 5 V
Output current: 6 A
Dimensions: 40 x 90 x 100 mm

Features of the power supply:

wide range of input voltage
built-in protection against: short circuit, overload, overvoltage
passive air cooling
mounted on a standard DIN rail TS35
built-in light indicator for network connection
DC OK indication signal
power consumption without payload - no more than 0.75W

The unit is mounted on a standard DIN rail TS35.

Overall dimensions: 40mm x 90mm x 100mm

Specifications

Main characteristics

Compatibility

Raspberry Pi 4 Model B, Raspberry Pi 3 Model B+, Raspberry Pi 3 Model B, Raspberry Pi 3 Model A+, Raspberry Pi 2 Model B v1.2, Raspberry Pi 1 Model B+, Raspberry Pi 1 Model A+, Raspberry Pi Zero/Zero W, Raspberry Pi Compute Module 3+ Development Kit, NVIDIA Jetson Nano Developer Kit

Country of origin

Made in China

Output current

6.0 A

Output voltage

5.0 V

Power

30.0 W

Power connector

terminal block

Type of accessory

Power supply
